Hoskins 3/4 in. Bob Valve
Hoskins 3/4 in. Bob Valve is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
All products will ship according to shipping option selected at checkout. Standard USPS and UPS average shipping times are 2-7 and freight up to 2 weeks. Allow extra time during peak season and the holidays. For more information see our Shipping Policy.
Hoskins 3/4 in. Bob Valve
Description
Description
Hoskins 3/4 in. Bob valve
Solid brass, with BOB cast into the body so there is no mistaking it once the cover is off. This is the valve that fills the tank: the float rod bolts to the lever arm, the float rides on the water, and the valve shuts as the level comes up.
Valve only
The float rod and float are separate items. These models run a 8 in. rod — we stock it alongside this valve. Size is set by your model and is not a matter of preference: too small and the tank will not keep up, too large and it will not shut off cleanly.
Specifications
- Size: 3/4 in.
- Material: solid brass
- Marking: BOB cast into the body
- Supplied as the valve only
Which Hoskins units take it
- Hoskins C75-16
- Hoskins C75-26
- Hoskins C95-16
- Hoskins C95-26
- Hoskins C120-16
- Hoskins C120-26
- Hoskins SC84-16
- Hoskins SC120-16
Hoskins steps up to the 3/4 in. at 75 in. of trough. A bigger orifice puts water back faster, which is what a long tank needs after a bunch has been through it.
The usual reasons a valve gets changed
Grit off a new line, mineral scale from well water, or a seat that has simply worn after enough seasons. If the tank overflows or dribbles constantly, the valve is the first thing to look at, then the float and the rod. All three sit together in the same insulated compartment.
See the rest of the Hoskins waterer parts, or the full Hoskins range. Not sure of your size? Send the model number from your service door through our contact form.
