Smidley Calf and Sheep Trough 9150ST
Smidley Calf and Sheep Trough 9150ST is backordered and will ship as soon as it is back in stock.
Features
Features
Specifications
Specifications
Delivery and Shipping
Delivery and Shipping
This item can be shipped UPS. Some UPS items are considered oversize and will incur additional shipping charges.
If you are looking at a bulk shipment, complete the Freight Quote request for best pricing.
Smidley Calf and Sheep Trough 9150ST
Smidley Calf and Sheep Trough 9150ST is backordered and will ship as soon as it is back in stock.
Description
Description
The same 52 inch length as the cattle trough, dropped to a height calves, sheep and lambs can actually drink from, with eleven gallons behind it.
The body is 100 percent 304 stainless steel in a heavy 14 gauge, inside and out. That matters most at the water line, which is where a painted or galvanized waterer starts to go first. There is no coating to chip and nothing underneath it to rust.
Electric heat and a self regulating thermostat come standard from the factory. The thermostat is what keeps the running cost down, because the heater only draws when the water actually needs it rather than running all winter. High density insulation through the body is what lets a modest heater hold the water open on a cold night, so the two work together.
The top cover lifts off by gravity, so cleaning it out is a bucket and a few minutes rather than a job with a wrench.
11 gallons of capacity, 20 1/2 inches wide by 24 1/2 inches high by 52 inches long. Built by Smidley in Britt, Iowa.
-
Smidley Hog Bar and Cattle Fountain Manual
The factory installation instructions, covering the Smidley hog bars and the cattle fountains in one manual.
Full Length Drinking Space at a Height Small Stock Can Reach.
The same 52 inch length as the cattle trough, dropped to a height calves, sheep and lambs can actually drink from, with eleven gallons behind it.
Product Comparison
The Calf and Sheep Trough first, then the waterers closest to it on capacity, herd size and heat. Compare them side by side.
| Facet | |||||
|---|---|---|---|---|---|
| By | |||||
| By | Smidley | Ritchie Industries | Ritchie Industries | Ritchie Industries | Ritchie Industries |
| Price | |||||
| Price |
Regular price
$1,779.00
Unit price
|
Sale price
$525.00
Regular price
$557.00
Unit price
|
Sale price
$900.00
Regular price
$940.00
Unit price
|
Sale price
$709.00
Regular price
$760.00
Unit price
|
Sale price
$1,119.99
Regular price
$1,176.99
Unit price
|
| Heat | |||||
| Heat | |||||
| Herd Capacity | |||||
| Herd Capacity | |||||
| Trough Capacity | |||||
| Trough Capacity | |||||
| Length | |||||
| Length | |||||
| Width | |||||
| Width | |||||
| Drink Height | |||||
| Drink Height | |||||
| Overall Height | |||||
| Overall Height | |||||
Need Parts for your Smidley?
Heating elements, thermostats, floats and valves, lids, lid rods and drain plugs, all stocked.
-
-
Regular price $31.00Unit price -
Smidley 14537 Float & Valve Complete — Short
Regular price $35.99Unit price -
Smidley W-Shaped Heating Element 245W for 2 drink 10045
Regular price $32.99Unit price -
Smidley Flush Plug – Drain Plug Part 915FP
Regular price $6.25Unit price -
Smidley High Pressure Valve with Hood 100927
Regular price $22.99Unit price -
Smidley D-Shaped Heating Element 245W 10038
Regular price $32.99Unit price -
Regular price $2.00Unit price
Frequently Asked Questions
How many head will the Calf and Sheep Trough water?
How many head will the Calf and Sheep Trough water?
Smidley does not publish a head count for this unit. Go by the 11 gallons of reserve and the 52 inches of drinking space, and if you are close to the line, size up rather than down.
Does it come heated, or is heat an add on?
Does it come heated, or is heat an add on?
It comes heated. Electric heat and a self regulating thermostat are standard from the factory. The thermostat is the part that keeps the bill down, because the heater only draws when the water actually needs it rather than running all winter.
Will it rust out at the water line?
Will it rust out at the water line?
It is 100 percent 304 stainless steel in a heavy 14 gauge, inside and out. There is no paint to chip and no galvanizing to wear through, which is what usually fails first on a steel waterer, right at the water line.
How much work is it to keep clean?
How much work is it to keep clean?
The top cover lifts off by gravity, so there is nothing to unbolt before you can get into the tank. Scrub it, rinse it and set the cover back on.
How does it ship?
How does it ship?
This one ships freight at 130 lb. You can also pick it up in Britt, Iowa if you would rather collect it yourself. Add it to the cart and enter your address at checkout, or send the freight quote request before you order.
