Miraco 425 Float Assembly

The Miraco 425 is the complete float assembly for the LilSpring line, the small one and two trough waterers that run off a single valve. It is the part that tells the valve when to stop filling: the bob float rides on the surface, the arm lifts with it, and at the height you set the valve closes.

What is in the assembly

• 342 nylon ratchet
• 343 brass thumbscrew
• 345 bob float, 4 x 4 in.
• 444 float arm, 2 1/2 in., stainless steel

Every metal part in the assembly is stainless steel apart from the brass thumbscrew, so nothing in it rusts in constant water.

How to set the water level

1. Loosen the brass thumbscrew a turn or two. There is no need to take it out.
2. Rotate the float arm inside the nylon ratchet. The ratchet is toothed, so the arm steps from one position to the next and holds where you leave it.
3. Raise the float to raise the shut off level and lower it to lower the level. A small move at the ratchet is a much bigger move out at the float.
4. Retighten the thumbscrew by hand. Brass against stainless is deliberate: it should never need a wrench and should never be forced.
5. Let the trough fill and check it. Most people set the level an inch or so below the overflow so wind and animal movement do not slop water out.

Specifications

• Miraco part number: 425
• Float arm: part 444, 2 1/2 in., stainless steel
• Bob float: part 345, 4 x 4 in., sealed
• Ratchet: part 342, toothed nylon
• Thumbscrew: part 343, brass, hand tight
• Manufacturer warranty: 1 year
• Sold: as a complete assembly

Fits these Miraco units: LilSpring 2700, 2800, 2900, 3000, 3100, 3200 and 3500, and the MiraFount 3310-4 hog waterer.

Not sure which assembly you need? Every Miraco float assembly carries the same nylon ratchet, brass thumbscrew and 4 x 4 in. bob float; only the float arm changes. See the full range of Miraco floats and assemblies.
